Vectors and Transformation GeometryEdexcel IGCSE Mathematics (4MA1)

Vectors

Work through the notes, try the practice questions, then take the quiz. The report tells you exactly what to revise next.

PreviousNext

Learn this Topic

Start with the slides for the quick version, then go deeper with the full study notes.

Short Study Notes in the form of Slides

Read the notes first. If the method in a worked example clicks, you're ready for the questions.

Page 1 / 0

Detailed Study Notes

Full prose, callouts and a recap — built for A* mastery, not just a quick scan.

Take these study notes with you

Download a branded PDF — full prose, callouts, recap and memorise list for Vectors , ready to print or save offline.

Vectors Study Notes — Edexcel IGCSE 4MA1 Higher Tier (2026 onwards)

Column vectors, addition, subtraction, scalar multiplication, magnitude, and vector geometry. A grade-A* topic on Paper 2H.

What you’ll learn

Mapped to the Cambridge IGCSE 4MA1 syllabus (2026 onwards).

5.1 — Understand vector notation, including column vectors.
5.1 — Add and subtract vectors; multiply by a scalar.
5.1 — Calculate the magnitude of a vector.
5.1 — Use vectors to solve geometric problems (position vectors, midpoints, parallel).

Vectors and column form

A vector has magnitude and direction. Column form makes arithmetic easy.

A vector is a quantity with both magnitude (length) and direction.

Examples: velocity, force, displacement.

Column form. $\mathbf{v} = \binom{x}{y}$ means: move $x$ in the horizontal direction, $y$ in the vertical.

Notation.

Bold lowercase: $\mathbf{a}, \mathbf{b}$ .
Or with an arrow: $\overrightarrow{AB}$ (vector from $A$ to $B$ ).
In handwriting: underline the letter ( $\underline{a}$ ).

Worked example. $\mathbf{a} = \binom{3}{2}$ . Direction: 3 right, 2 up. Magnitude: $\sqrt{9 + 4} = \sqrt{13}$ .

Free vs position vectors.

A free vector can be drawn anywhere — only direction and magnitude matter.
A position vector is anchored at the origin: $\overrightarrow{OA} = \mathbf{a}$ .

Equal vectors. Two vectors are equal if they have the SAME magnitude AND the SAME direction. They can be in different places on the diagram!

Vector: magnitude AND direction.
Column form: $\binom{x}{y}$ .
Bold or arrow notation.
Equal: same magnitude AND direction.

Adding, subtracting, scalar multiplying

Componentwise. Easy.

Addition. $\binom{a}{b} + \binom{c}{d} = \binom{a + c}{b + d}$ .

Subtraction. $\binom{a}{b} - \binom{c}{d} = \binom{a - c}{b - d}$ .

Scalar multiplication. $k \binom{a}{b} = \binom{ka}{kb}$ — both components scale.

Worked example. $\mathbf{a} = \binom{3}{2}$ , $\mathbf{b} = \binom{-1}{4}$ .

$\mathbf{a} + \mathbf{b} = \binom{2}{6}$
$\mathbf{a} - \mathbf{b} = \binom{4}{-2}$
$2\mathbf{a} = \binom{6}{4}$
$3\mathbf{a} - 2\mathbf{b} = \binom{9}{6} - \binom{-2}{8} = \binom{11}{-2}$

Geometric interpretation.

Adding vectors: place tail-to-head; resultant goes from start of first to end of second.
Subtracting $\mathbf{a} - \mathbf{b}$ : same as $\mathbf{a} + (-\mathbf{b})$ . The vector $-\mathbf{b}$ is $\mathbf{b}$ in the opposite direction.
Scalar $k > 1$ : stretch. $0 < k < 1$ : shrink. $k < 0$ : reverse direction.

Edexcel tip. Show your work in column form for full method marks. Don't try to do mental arithmetic on a tricky 3-step calculation.

Add/subtract componentwise.
$k\mathbf{v}$ scales BOTH components.
Tail-to-head for geometry.
Negative scalar reverses direction.

Magnitude (length) of a vector

Pythagoras. Use BOTH components.

The magnitude $|\mathbf{v}|$ is the length of the vector.

$|\mathbf{v}| = \sqrt{x^{2} + y^{2}}$

This is just Pythagoras applied to the right triangle with legs $x$ and $y$ .

Worked example. $\mathbf{v} = \binom{6}{8}$ . $|\mathbf{v}| = \sqrt{36 + 64} = \sqrt{100} = 10$ .

Worked example. $\mathbf{u} = \binom{-3}{4}$ . $|\mathbf{u}| = \sqrt{9 + 16} = \sqrt{25} = 5$ . Magnitude is always positive — sign of components doesn't matter (you square them).

Common pitfall. Don't forget the SQUARE ROOT. The expression $x^2 + y^2$ alone is NOT the magnitude.

Worked qualitative. Why Pythagoras? The vector $\binom{x}{y}$ is the hypotenuse of a right triangle with horizontal leg $x$ and vertical leg $y$ . By Pythagoras, hypotenuse $= \sqrt{x^2 + y^2}$ .

$|\mathbf{v}| = \sqrt{x^{2} + y^{2}}$ .
Always positive.
Squaring removes sign.
It's just Pythagoras.

Vector geometry — position vectors and $\overrightarrow{AB}$

$\overrightarrow{AB} = \mathbf{b} - \mathbf{a}$ . Master this.

Position vectors. Given an origin $O$ , every point $A$ has a position vector $\overrightarrow{OA}$ . We often label this $\mathbf{a}$ .

The fundamental rule. $\overrightarrow{AB} = \mathbf{b} - \mathbf{a}$ — END point minus START point.

Memory aid. " $AB$ goes FROM $A$ TO $B$ — so subtract $A$ from $B$ ."

Worked example. $\overrightarrow{OA} = \binom{2}{1}$ , $\overrightarrow{OB} = \binom{5}{4}$ .

$\overrightarrow{AB} = \overrightarrow{OB} - \overrightarrow{OA} = \binom{3}{3}$ .
$\overrightarrow{BA} = -\overrightarrow{AB} = \binom{-3}{-3}$ (opposite direction).

Midpoint. $M$ is midpoint of $AB$ : $\overrightarrow{OM} = \dfrac{1}{2}(\mathbf{a} + \mathbf{b})$

Derivation:

$\overrightarrow{AM} = \dfrac{1}{2}\overrightarrow{AB} = \dfrac{1}{2}(\mathbf{b} - \mathbf{a})$
$\overrightarrow{OM} = \overrightarrow{OA} + \overrightarrow{AM} = \mathbf{a} + \dfrac{1}{2}(\mathbf{b} - \mathbf{a}) = \dfrac{1}{2}(\mathbf{a} + \mathbf{b})$ .

Dividing in a ratio. If $P$ divides $AB$ in ratio $m:n$ : $\overrightarrow{OP} = \mathbf{a} + \dfrac{m}{m + n}(\mathbf{b} - \mathbf{a})$

Edexcel tip. Vector geometry questions are 4-6 mark mini-proofs. Mark schemes credit:

Setting up vectors in terms of $\mathbf{a}, \mathbf{b}$ .
Using $\overrightarrow{AB} = \mathbf{b} - \mathbf{a}$ correctly.
Final simplified expression.

$\overrightarrow{AB} = \mathbf{b} - \mathbf{a}$ .
Midpoint: $\dfrac{1}{2}(\mathbf{a} + \mathbf{b})$ .
$\overrightarrow{BA} = -\overrightarrow{AB}$ .
Build a path: A → known point → B.

See the full worked example for vectors →

Parallel and collinear vectors

Parallel: scalar multiple. Collinear: parallel AND share a point.

Parallel vectors. Two vectors are parallel if and only if one is a scalar multiple of the other.

$\mathbf{u} \parallel \mathbf{v} \iff \mathbf{u} = k \mathbf{v} \text{ for some scalar } k \ne 0$

Worked example. $\overrightarrow{PQ} = 3\mathbf{a} + 2\mathbf{b}$ and $\overrightarrow{RS} = 6\mathbf{a} + 4\mathbf{b}$ .

$\overrightarrow{RS} = 2(3\mathbf{a} + 2\mathbf{b}) = 2 \overrightarrow{PQ}$ .
Since one is a scalar multiple of the other, they are parallel.

Worked example. $\binom{3}{2}$ and $\binom{9}{6}$ — parallel? Yes: $\binom{9}{6} = 3\binom{3}{2}$ .

Worked example. $\binom{3}{2}$ and $\binom{4}{6}$ — parallel? Check ratio: $4/3 \ne 6/2$ . NOT parallel.

Collinear points. $A, B, C$ are collinear (on the same line) if $\overrightarrow{AB}$ and $\overrightarrow{AC}$ are parallel.

Edexcel proof template.

Calculate the two vectors.
Show one is a scalar multiple of the other.
State: " $\overrightarrow{XY} = k \overrightarrow{PQ}$ , so they are parallel."

For collinear: also state they share a common point.

Parallel: one is scalar multiple.
Same OR opposite direction.
Different magnitudes ok.
Collinear: parallel + shared point.

See the full worked example for vectors →

How it’s examined

Vectors appear on EVERY Higher Tier paper. Paper 2H typically has a 4-6 mark mini-proof using $\overrightarrow{AB} = \mathbf{b} - \mathbf{a}$ and midpoints/ratios. Examiner reports flag: (1) wrong direction $AB$ vs $BA$ , (2) not simplifying the final answer, (3) jumping to conclusion without justification.

Sources: Pearson Edexcel International GCSE Mathematics A 4MA1 specification (2026 onwards); 4MA1 Examiner Reports — Jan and May/Jun 2022-2024 series; Past Papers — 4MA1/2H May/Jun 2024. Last reviewed 2026-05-07.

Master this Topic

Worked examples, formulae, definitions and the mistakes examiners flag — everything you need to push from a pass to an A*.

Take this whole topic with you

Download a branded revision sheet — worked examples, formulae, definitions and common mistakes for Vectors , ready to print or save as PDF.

Step-by-step worked examples — Vectors

Step-by-step solutions to past-paper-style questions on vectors , written exactly the way a tutor would explain them at the board.

1Vector arithmetic
Foundation• vector
Question
Given $\mathbf{a} = \binom{3}{2}$ and $\mathbf{b} = \binom{-1}{4}$ , find $\mathbf{a} + \mathbf{b}$ and $2\mathbf{a} - \mathbf{b}$ .
Step-by-step solution
1. Step 1
  $\mathbf{a} + \mathbf{b} = \binom{3 + (-1)}{2 + 4} = \binom{2}{6}$ .
2. Step 2
  $2\mathbf{a} = \binom{6}{4}$ . So $2\mathbf{a} - \mathbf{b} = \binom{6 - (-1)}{4 - 4} = \binom{7}{0}$ .
Answer
$\mathbf{a} + \mathbf{b} = \binom{2}{6}$ . $2\mathbf{a} - \mathbf{b} = \binom{7}{0}$ .
2Magnitude (length) of a vector
Foundation• magnitude
Question
Find the magnitude of $\mathbf{v} = \binom{6}{8}$ .
Step-by-step solution
1. Step 1
  $|\mathbf{v}| = \sqrt{x^{2} + y^{2}}$ (Pythagoras).
2. Step 2
  $|\mathbf{v}| = \sqrt{36 + 64} = \sqrt{100} = 10$ .
Answer
$|\mathbf{v}| = 10$
3Vector geometry — find a position vector
Higher• Adapted from 4MA1/2H May/Jun 2024 Q24• vector geometry
Question
$\overrightarrow{OA} = \mathbf{a}$ , $\overrightarrow{OB} = \mathbf{b}$ . $M$ is the midpoint of $AB$ . Express $\overrightarrow{OM}$ in terms of $\mathbf{a}$ and $\mathbf{b}$ .
Step-by-step solution
1. Step 1
  $\overrightarrow{AB} = \mathbf{b} - \mathbf{a}$ .
2. Step 2
  $M$ is midpoint, so $\overrightarrow{AM} = \dfrac{1}{2}\overrightarrow{AB} = \dfrac{1}{2}(\mathbf{b} - \mathbf{a})$ .
3. Step 3
  $\overrightarrow{OM} = \overrightarrow{OA} + \overrightarrow{AM} = \mathbf{a} + \dfrac{1}{2}(\mathbf{b} - \mathbf{a}) = \dfrac{1}{2}\mathbf{a} + \dfrac{1}{2}\mathbf{b} = \dfrac{1}{2}(\mathbf{a} + \mathbf{b})$ .
Answer
$\overrightarrow{OM} = \dfrac{1}{2}(\mathbf{a} + \mathbf{b})$
4Parallel vectors
Higher• parallel
Question
Show that $\overrightarrow{PQ} = 3\mathbf{a} + 2\mathbf{b}$ and $\overrightarrow{RS} = 6\mathbf{a} + 4\mathbf{b}$ are parallel.
Step-by-step solution
1. Step 1
  Two vectors are PARALLEL if one is a scalar multiple of the other.
2. Step 2
  $\overrightarrow{RS} = 2(3\mathbf{a} + 2\mathbf{b}) = 2 \overrightarrow{PQ}$ .
3. Step 3
  Since $\overrightarrow{RS}$ is a scalar multiple of $\overrightarrow{PQ}$ , they are parallel.
Answer
$\overrightarrow{RS} = 2 \overrightarrow{PQ}$ , so parallel.
Examiner tip
To prove parallelism: show one vector is a scalar multiple of the other. Mark scheme awards M1 for setup, A1 for the conclusion.

Key Formulae — Vectors

The formulae you need to memorise for vectors on the Pearson Edexcel IGCSE 4MA1 paper, with every variable defined in plain English and a note on when to use it.

Magnitude of a vector
$|\mathbf{v}| = \sqrt{x^{2} + y^{2}}$
$x, y$
components of vector
When to use
Finding the length of a vector.
Example
$\binom{3}{4}$ : $|\mathbf{v}| = 5$ .

Key Definitions and Keywords — Vectors

Definitions to memorise and the exact keywords mark schemes credit for vectors answers — sharpened from recent examiner reports for the 2026 Pearson Edexcel IGCSE 4MA1 sitting.

Vector
Examiner keyword
A quantity with both MAGNITUDE and DIRECTION. Written as a column matrix or with an arrow.
Example
Velocity, force, displacement.
Position vector
$\overrightarrow{OA}$ — vector from the origin $O$ to a point $A$ .
Parallel vectors
Examiner keyword
Two vectors with the same OR opposite direction. One is a scalar multiple of the other.

Common Mistakes and Misconceptions — Vectors

The traps other students keep falling into on vectors questions — taken from recent Pearson Edexcel IGCSE 4MA1 examiner reports and mark schemes — and how to avoid them.

✕Going wrong way: $\overrightarrow{AB}$ vs $\overrightarrow{BA}$
Why it happens
Direction reversed.
How to avoid it
$\overrightarrow{AB} = \mathbf{b} - \mathbf{a}$ (END minus START).
✕Confusing 'parallel' with 'equal'
Why it happens
Both involve same direction.
How to avoid it
PARALLEL: same or opposite direction (different lengths). EQUAL: same direction AND same magnitude.
✕Using only one component for magnitude
Why it happens
Forgetting Pythagoras.
How to avoid it
$|\mathbf{v}| = \sqrt{x^{2} + y^{2}}$ . Use BOTH components.

Practice questions

Exam-style questions with step-by-step worked solutions. Try one before checking the method.

Past paper style quiz

Get a report showing which sub-topics you've nailed and which ones still need work.

Video lesson

Short walkthrough of the concepts students most often get stuck on.

Vectors — frequently asked questions

The things students keep getting wrong in this sub-topic, answered.

Vectors

Short Study Notes in the form of Slides

Detailed Study Notes

What you’ll learn

How it’s examined

1Vector arithmetic

2Magnitude (length) of a vector

3Vector geometry — find a position vector

4Parallel vectors

Magnitude of a vector

Vector

Position vector

Parallel vectors

✕Going wrong way: AB→\overrightarrow{AB}AB vs BA→\overrightarrow{BA}BA

✕Confusing 'parallel' with 'equal'

✕Using only one component for magnitude

Practice questions

Past paper style quiz

Assess your understanding

Video lesson

Vectors — frequently asked questions

✕Going wrong way: $\overrightarrow{AB}$ vs $\overrightarrow{BA}$
