Venn Diagrams and Two-Way Tables Study Notes — Edexcel IGCSE 4MA1 Higher Tier (2026 onwards)

Venn diagrams for sets/probability; two-way tables for cross-categorising. Conditional probability from both is heavily examined.

What you’ll learn

Mapped to the Cambridge IGCSE 4MA1 syllabus (2026 onwards).

6.6 — Use set notation: $\cap, \cup, ', \xi$ .
6.6 — Construct and interpret Venn diagrams (2 and 3 sets).
6.6 — Calculate probabilities using Venn diagrams.
6.6 — Construct and interpret two-way tables.
6.6 — Calculate conditional probability from a Venn diagram or two-way table.

Set notation

Master the four symbols: $\cap, \cup, ', \xi$ .

Set — a collection of distinct objects.

Universal set $\xi$ — everything under consideration. Drawn as a rectangle.

$A \cap B$ (A intersection B) — elements in BOTH $A$ AND $B$ . The overlap.

$A \cup B$ (A union B) — elements in $A$ OR $B$ (or both).

$A'$ (complement of $A$ ) — elements in $\xi$ but NOT in $A$ .

Memory aid for $\cap$ vs $\cup$ :

$\cap$ — pointed top (like the 'A' in AND). Intersection.
$\cup$ — opens upward like a cup. Union.

Examples. $\xi = \{1, 2, 3, 4, 5, 6, 7, 8\}$ , $A = \{2, 4, 6\}$ , $B = \{4, 5, 6, 7\}$ .

$A \cap B = \{4, 6\}$ .
$A \cup B = \{2, 4, 5, 6, 7\}$ .
$A' = \{1, 3, 5, 7, 8\}$ (not in $A$ ).
$(A \cup B)' = \{1, 3, 8\}$ (not in either).

Edexcel tip. Set questions sometimes use words: "elements in $A$ but not in $B$ " = $A \cap B'$ = $A$ minus the overlap.

$\cap$ = AND (intersection).
$\cup$ = OR (union).
$A'$ = NOT $A$ (complement).
$\xi$ = universal (everything).

Venn diagrams (2 and 3 sets)

Fill from the INTERSECTION outwards.

Two-set Venn. Two overlapping circles inside a rectangle ( $\xi$ ). Four regions:

$A$ only (left).
$A \cap B$ (overlap).
$B$ only (right).
Outside both (corner of rectangle).

Filling rule. Always start with the intersection.

Worked example. $|A| = 12$ , $|B| = 15$ , $|A \cap B| = 7$ , total = 25.

$|A \cap B| = 7$ in the overlap.
$A$ only $= 12 - 7 = 5$ .
$B$ only $= 15 - 7 = 8$ .
Outside $= 25 - (5 + 7 + 8) = 5$ .

Sanity check: $5 + 7 + 8 + 5 = 25$ . ✓

Three-set Venn. Three overlapping circles, EIGHT regions. Same rule: start with the central intersection $A \cap B \cap C$ , work outwards.

Inclusion-exclusion (3 sets). $|A \cup B \cup C| = |A| + |B| + |C| - |A \cap B| - |A \cap C| - |B \cap C| + |A \cap B \cap C|$

(Add singles, subtract pairs, add the triple — to correct for double/triple counting.)

Edexcel tip. Mark schemes for filling Venns:

M1: intersection placed correctly.
M1: 'only' regions correct.
A1: outside region correct.
B1: total checks out.

Start with intersection.
$A$ only = $|A|$ − intersection.
Outside = total − (sum of regions).
Always check sum equals total.

See the full worked example for venn diagrams and tables →

Probability from a Venn diagram

Count the favourable region; divide by total.

Once a Venn is filled, probability questions are direct.

Worked example (continuing). 25 students. $|A \cap B| = 7$ , $A$ only $= 5$ , $B$ only $= 8$ , outside $= 5$ .

$P(A) = 12/25$ (size of $A$ over total).
$P(A \cap B) = 7/25$ .
$P(A \cup B) = 20/25 = 4/5$ .
$P(\text{neither}) = 5/25 = 1/5$ .
$P(\text{exactly one}) = (5 + 8)/25 = 13/25$ .

Conditional probability from Venn. $P(A | B)$ = "probability $A$ given $B$ ".

Restrict attention to $B$ only.
Of those, find how many are in $A$ .

$P(A | B) = \dfrac{P(A \cap B)}{P(B)} = \dfrac{|A \cap B|}{|B|}$

Worked example. $P(A | B) = 7/15$ (7 in both, 15 in $B$ in total).

Edexcel tip. When you see "given", "if it is known", "out of those who" — that's a conditioning signal. The denominator becomes the conditioning set.

Count favourable region.
Denominator = total (or conditioning set).
$P(A|B) = |A \cap B| / |B|$ .
Conditional changes the denominator.

See the full worked example for venn diagrams and tables →

Two-way tables

Cross-categorise two variables. Row totals + column totals.

A two-way table sorts data by two categorical variables — one across rows, one across columns.

Example.

	Walks	Bus	Car	Total
Male	12	8	6	26
Female	14	12	8	34
Total	26	20	14	60

Each cell = number with that combination. Totals row + column show one-variable counts.

Reading probabilities.

$P(\text{walks AND male}) = 12/60 = 1/5$ .
$P(\text{walks}) = 26/60 = 13/30$ .
$P(\text{walks} | \text{male}) = 12/26 = 6/13$ (restricted to male row, total 26).

Filling missing cells. Use row + column totals to back-fill.

Worked example. Below, missing cells marked $?$ .

	A	B	Total
X	?	5	12
Y	7	?	18
Total	?	?	30

Row X total = 12, B-X = 5 → A-X = 7.
Row Y total = 18, A-Y = 7 → B-Y = 11.
Col A total = A-X + A-Y = 7 + 7 = 14.
Col B total = 5 + 11 = 16. Check: 14 + 16 = 30. ✓

Edexcel tip. Rows + columns + totals must all be consistent. A two-way table problem reduces to systematic addition/subtraction.

Two categories cross-tabulated.
Row + column totals give one-variable counts.
Conditional: restrict to row or column.
Back-fill via subtraction.

How it’s examined

Venns and two-way tables are 4-6 mark questions on both papers. Conditional probability from these is the most common Higher Tier extension. Examiner reports flag: (1) putting $|A|$ in the 'only $A$ ' region, (2) wrong denominator for conditional, (3) confusing $\cap$ with $\cup$ .

Sources: Pearson Edexcel International GCSE Mathematics A 4MA1 specification (2026 onwards); 4MA1 Examiner Reports — Jan and May/Jun 2022-2024 series; Past Papers — 4MA1/1H May/Jun 2024, 4MA1/2H Jan 2024. Last reviewed 2026-05-07.

Master this Topic

Worked examples, formulae, definitions and the mistakes examiners flag — everything you need to push from a pass to an A*.

Take this whole topic with you

Download a branded revision sheet — worked examples, formulae, definitions and common mistakes for Venn Diagrams and Tables, ready to print or save as PDF.

Step-by-step worked examples — Venn Diagrams and Tables

Step-by-step solutions to past-paper-style questions on venn diagrams and tables, written exactly the way a tutor would explain them at the board.

1Fill a Venn diagram
Higher• venn
Question
$|A| = 12$ , $|B| = 15$ , $|A \cap B| = 7$ , total = 25. Fill the Venn diagram.
Step-by-step solution
1. Step 1
  Start with the intersection: $|A \cap B| = 7$ .
2. Step 2
  $A$ only = $|A| - |A \cap B| = 12 - 7 = 5$ .
3. Step 3
  $B$ only = $15 - 7 = 8$ .
4. Step 4
  Outside = total − (5 + 7 + 8) = $25 - 20 = 5$ .
Answer
$A$ only: 5; intersection: 7; $B$ only: 8; outside: 5. Total = 25.
Examiner tip
ALWAYS start with the intersection. Mark scheme awards M1 for correctly placed intersection.
2Probability from a Venn diagram
Higher• Adapted from 4MA1/1H May/Jun 2024 Q23• venn, probability
Question
From the diagram above, find $P(A \cap B)$ , $P(A \cup B)$ , $P(\text{neither})$ .
Step-by-step solution
1. Step 1
  $P(A \cap B) = 7/25$ .
2. Step 2
  $P(A \cup B) = (5 + 7 + 8)/25 = 20/25 = 4/5$ .
3. Step 3
  $P(\text{neither}) = 5/25 = 1/5$ .
Answer
$P(A \cap B) = 7/25$ ; $P(A \cup B) = 4/5$ ; $P(\text{neither}) = 1/5$ .
3Conditional probability from Venn
Higher• conditional, venn
Question
From the diagram, find $P(A | B)$ — probability $A$ given $B$ .
Step-by-step solution
1. Step 1
  Restrict to $B$ : there are 15 in $B$ in total.
2. Step 2
  Of those, 7 are also in $A$ . $P(A | B) = 7/15$ .
Answer
$P(A | B) = 7/15$
Examiner tip
Conditional: condition is the new total. $P(A|B)$ = (in both) / (in $B$ ).
4Two-way table
Higher• Adapted from 4MA1/2H Jan 2024 Q15• two-way table
Question
Two-way table of students by gender and travel mode. Find $P(\text{walks AND male})$ .
Step-by-step solution
1. Step 1
  Read the cell: e.g., 12 students walk AND are male.
2. Step 2
  Total students = 60.
3. Step 3
  $P = 12/60 = 1/5$ .
Answer
$P(\text{walks AND male}) = 1/5$

Key Formulae — Venn Diagrams and Tables

The formulae you need to memorise for venn diagrams and tables on the Pearson Edexcel IGCSE 4MA1 paper, with every variable defined in plain English and a note on when to use it.

Conditional probability
$P(A | B) = \dfrac{P(A \cap B)}{P(B)}$
$P(A | B)$
probability of $A$ given $B$
When to use
When restricting attention to a subset.
Example
From Venn: divide intersection by the conditioning set's count.
Union (general)
$P(A \cup B) = P(A) + P(B) - P(A \cap B)$
When to use
Probability of A or B (not necessarily mutually exclusive).

Key Definitions and Keywords — Venn Diagrams and Tables

Definitions to memorise and the exact keywords mark schemes credit for venn diagrams and tables answers — sharpened from recent examiner reports for the 2026 Pearson Edexcel IGCSE 4MA1 sitting.

Set
A collection of objects (elements). Notation: $A = \{1, 2, 3\}$ .
Intersection
Examiner keyword
$A \cap B$ — elements in BOTH $A$ AND $B$ .
Union
Examiner keyword
$A \cup B$ — elements in $A$ OR $B$ (or both).
Complement
Examiner keyword
$A'$ — elements NOT in $A$ . Within the universal set.
Conditional probability
Examiner keyword
$P(A | B)$ — probability of $A$ given $B$ has occurred.

Common Mistakes and Misconceptions — Venn Diagrams and Tables

The traps other students keep falling into on venn diagrams and tables questions — taken from recent Pearson Edexcel IGCSE 4MA1 examiner reports and mark schemes — and how to avoid them.

✕Filling a Venn diagram from outside in
4MA1 — examiner reports 2022-2024
Why it happens
Working through the question in order.
How to avoid it
Start with the INTERSECTION. Then 'only $A$ ' = $|A|$ minus intersection. Then 'only $B$ '. Then 'outside'.
✕Wrong denominator for conditional probability
Why it happens
Using total instead of the conditioning set.
How to avoid it
$P(A | B)$ : denominator is the count in $B$ , NOT the total.
✕Confusing $\cup$ (or) with $\cap$ (and)
Why it happens
Symbols look similar.
How to avoid it
$\cap$ (and, intersection) — pointed bottom, like the top of an 'A' for 'AND'. $\cup$ (or, union) — open top.
✕Double-counting the intersection in $|A \cup B|$
Why it happens
$|A| + |B|$ counts the intersection twice.
How to avoid it
$|A \cup B| = |A| + |B| - |A \cap B|$ — subtract the overlap.
