Geometry and TrigonometryEdexcel IGCSE Mathematics (4MA1)

Construction

Work through the notes, try the practice questions, then take the quiz. The report tells you exactly what to revise next.

Previous Next

Learn this Topic

Start with the slides for the quick version, then go deeper with the full study notes.

Short Study Notes in the form of Slides

Read the notes first. If the method in a worked example clicks, you're ready for the questions.

Page 1 / 0

Detailed Study Notes

Full prose, callouts and a recap — built for A* mastery, not just a quick scan.

Take these study notes with you

Download a branded PDF — full prose, callouts, recap and memorise list for Construction , ready to print or save offline.

Constructions and Loci Study Notes — Edexcel IGCSE 4MA1 Higher Tier (2026 onwards)

Compass-and-ruler constructions: bisectors, perpendiculars. Loci: equidistant patterns. Always show ALL construction arcs.

What you’ll learn

Mapped to the Cambridge IGCSE 4MA1 syllabus (2026 onwards).

4.6 — Construct perpendicular bisectors and angle bisectors using compasses.
4.6 — Find the locus of points satisfying given conditions.

Constructions

Compass and ruler. Show all arcs.

Perpendicular bisector of $AB$ .

Set compass radius MORE than half $|AB|$ .
From $A$ : draw arc above and below $AB$ .
From $B$ (SAME radius): draw arcs that intersect the first arcs.
Connect the two intersection points.
The line passes through the midpoint and is perpendicular.

Angle bisector of $\angle BAC$ .

From $A$ : draw an arc cutting both rays $AB$ and $AC$ . Call the intersections $P$ and $Q$ .
From $P$ : draw an arc into the angle.
From $Q$ (same radius): draw an arc that meets the first.
Connect $A$ to that intersection.
The line bisects the angle.

Perpendicular from a point to a line.

For point $P$ NOT on line $AB$ :

From $P$ : draw arcs cutting line $AB$ at two points (call them $X, Y$ ).
From $X, Y$ : draw arcs meeting on the OTHER SIDE of the line.
Connect $P$ to the new intersection.

Worked qualitative. Why does same-radius from two points give the perpendicular bisector?

Each arc is the locus of points equidistant from the centre.
Their intersection is equidistant from BOTH points.
The line connecting two equidistant points is the perpendicular bisector.

Edexcel tip. Construction arcs MUST BE VISIBLE. Erasing them loses you the M1 mark.

Same radius for both arcs.
Show all construction arcs.
Use ruler ONLY to connect points.
Sharp pencil for accuracy.

Loci — equidistant patterns

Standard loci based on what's equidistant.

Locus = path/region of points satisfying a condition.

Standard loci:

From	Locus
Single point	Circle (centre at point, radius = distance)
Single line	Pair of parallel lines (distance away each side)
Two points (equidistant)	Perpendicular bisector
Two lines (equidistant)	Angle bisector
Inside region	Intersection of multiple loci

Worked examples:

'Within $5$ cm of $P$ .' Disc centred at $P$ , radius $5$ .

' $3$ cm from line $AB$ .' Two parallel lines, $3$ cm above and below $AB$ .

'Closer to $A$ than $B$ .' Region on $A$ 's side of the perpendicular bisector of $AB$ .

'Within $4$ cm of $A$ AND closer to $A$ than $B$ .' Intersection of disc and half-plane.

Combined loci. Often Edexcel asks for the region satisfying TWO conditions. Find each locus, shade where they overlap.

Worked qualitative. Why does 'closer to $A$ than $B$ ' give a half-plane?

Equal distance: perpendicular bisector.
Closer to $A$ : the side OF the bisector that contains $A$ .
That's a half-plane.

Edexcel tip. When asked for a region (not just a curve), SHADE the area. Mark schemes credit the shading.

From point: circle.
From line: parallel lines.
Equidistant from 2 points: perp bisector.
Equidistant from 2 lines: angle bisector.
Combined: intersect loci.

How it’s examined

Constructions on Higher Tier (3-5 marks). Examiner reports flag (1) erasing arcs, (2) using different radii, (3) wrong locus shape.

Sources: Pearson Edexcel International GCSE Mathematics A 4MA1 specification (2026 onwards); 4MA1 Examiner Reports — Jan and May/Jun 2022-2024 series; Past Papers — 4MA1/1H May/Jun 2024. Last reviewed 2026-05-07.

Master this Topic

Worked examples, formulae, definitions and the mistakes examiners flag — everything you need to push from a pass to an A*.

Take this whole topic with you

Download a branded revision sheet — worked examples, formulae, definitions and common mistakes for Construction , ready to print or save as PDF.

Step-by-step worked examples — Construction

Step-by-step solutions to past-paper-style questions on construction , written exactly the way a tutor would explain them at the board.

1Construct a perpendicular bisector
Foundation• construction, bisector
Question
Describe how to construct the perpendicular bisector of line segment $AB$ .
Step-by-step solution
1. Step 1
  Set compass to MORE than half the length of $AB$ .
2. Step 2
  From $A$ , draw arcs above and below the line.
3. Step 3
  Without changing the compass, do the same from $B$ .
4. Step 4
  Two pairs of arcs intersect — one pair above, one below the line. Draw a line through both intersections. This is the perpendicular bisector.
Answer
Draw arcs from $A$ , then $B$ , with same compass setting. Connect the intersections.
Examiner tip
Mark schemes credit ARCS being clearly visible. Don't erase them.
2Construct an angle bisector
Higher• construction, angle bisector
Question
Bisect angle $\angle BAC$ .
Step-by-step solution
1. Step 1
  From $A$ , draw an arc that crosses both $AB$ and $AC$ . Let the intersections be $P$ and $Q$ .
2. Step 2
  From $P$ and $Q$ , draw arcs (same radius) that intersect.
3. Step 3
  Draw a line from $A$ through this intersection.
Answer
Arc from $A$ through both rays. Equal arcs from intersections meet inside angle. Line from $A$ through that point bisects.
3Locus equidistant from two points
Higher• locus
Question
Sketch the locus of points equidistant from $A(0, 0)$ and $B(8, 0)$ .
Step-by-step solution
1. Step 1
  Equidistant from two points = perpendicular bisector of the line segment joining them.
2. Step 2
  Midpoint of $A, B$ is $(4, 0)$ . Perpendicular bisector is the vertical line $x = 4$ .
Answer
$x = 4$ (vertical line through $(4, 0)$ ).
4Locus equidistant from a line
Higher• locus
Question
Describe the locus of points $5$ cm from a fixed point $P$ .
Step-by-step solution
1. Step 1
  Equidistant from a single point = a CIRCLE centered at that point.
2. Step 2
  Centre at $P$ , radius $5$ cm.
Answer
Circle centre $P$ , radius $5$ cm.
Examiner tip
Loci patterns: equidistant from a POINT → CIRCLE. From a LINE → parallel line. From TWO POINTS → perpendicular bisector. From a CORNER → angle bisector.

Key Definitions and Keywords — Construction

Definitions to memorise and the exact keywords mark schemes credit for construction answers — sharpened from recent examiner reports for the 2026 Pearson Edexcel IGCSE 4MA1 sitting.

Locus
Examiner keyword
A set of points satisfying a given condition. The 'path' of points.
Example
Locus of points $5$ cm from $P$ = circle.
Bisector
A line that splits something into two equal parts. Perpendicular bisector splits a line segment. Angle bisector splits an angle.
Equidistant
At equal distance from each of two or more given things.

Common Mistakes and Misconceptions — Construction

The traps other students keep falling into on construction questions — taken from recent Pearson Edexcel IGCSE 4MA1 examiner reports and mark schemes — and how to avoid them.

✕Erasing the construction arcs after drawing the line
Why it happens
Tidying up.
How to avoid it
LEAVE the arcs visible. Mark schemes give marks for the construction METHOD shown. Erasing loses marks.
✕Using DIFFERENT radius from $A$ and $B$
Why it happens
Adjusting compass.
How to avoid it
Set compass once, USE THE SAME radius for both arcs (from $A$ and $B$ ). Symmetry depends on this.
✕Drawing wrong shape for locus
Why it happens
Confusing equidistant patterns.
How to avoid it
Memorise: from POINT → circle. From LINE → parallel line. From TWO POINTS → perpendicular bisector. From CORNER → angle bisector.

Practice questions

Exam-style questions with step-by-step worked solutions. Try one before checking the method.

Past paper style quiz

Get a report showing which sub-topics you've nailed and which ones still need work.

Video lesson

Short walkthrough of the concepts students most often get stuck on.

Construction — frequently asked questions

The things students keep getting wrong in this sub-topic, answered.
