Carboxylic acid structure and the –COOH functional group (spec 4.32)
CₙH₂ₙ₊₁COOH. Methanoic, ethanoic, propanoic. Sharp / pungent smells. Soluble in water.
Carboxylic acids are a homologous series of organic compounds characterised by the CARBOXYL group –COOH at the end of an alkyl chain.
General formula: (where n = 0, 1, 2,...).
For methanoic acid n = 0 (the alkyl group is just H — HCOOH). For ethanoic acid n = 1 (CH₃COOH). For propanoic acid n = 2 (C₂H₅COOH or CH₃CH₂COOH).
The carboxyl group: –COOH.
The –COOH group consists of TWO functional groups merged into one:
O
||
─ C ─ O ─ H
│
(rest of molecule)
- A C=O double bond (carbonyl).
- An O–H group bonded to the same carbon (hydroxyl).
Together this combination makes the H atom of the –OH part ACIDIC — it can dissociate as H⁺. This is why carboxylic acids are acidic.
First three carboxylic acids.
| n | Name | Structural formula | Common name | Source / use |
|---|---|---|---|---|
| 0 | Methanoic acid | HCOOH | Formic acid | Ant stings, nettle hairs |
| 1 | Ethanoic acid | CH₃COOH (or HC₂H₃O₂) | Acetic acid | VINEGAR (~ 5% aqueous solution); food preservative |
| 2 | Propanoic acid | CH₃CH₂COOH or C₂H₅COOH | Propionic acid | Mould inhibitor in bread |
| 3 | Butanoic acid | C₃H₇COOH | Butyric acid | Rancid butter, body odour |
Naming pattern. Take the alkane name (methane, ethane, propane) → drop '-e' → add -oic acid suffix. The carboxyl C is counted as carbon 1. So 'propanoic acid' has 3 carbons total (including the COOH carbon), with the carboxyl group on C1.
Displayed formula of ethanoic acid.
H O
| ||
H — C ── C ── O ── H
|
H
Three carbons total? Wait — only TWO carbons in ethanoic acid! Let me re-draw:
H O
| ||
H — C ──── C
| |
H O
|
H
Two carbons. The –CH₃ is the methyl group (from the alkane stem); the –COOH on C1 is the carboxyl group. So CH₃ + COOH = CH₃COOH.
Physical properties.
| Property | Value (for ethanoic acid) | Reason |
|---|---|---|
| State at room T | Liquid (mp 16 °C, bp 118 °C) | H-bonding between molecules |
| Smell | Sharp / pungent (vinegar) | Volatile + irritant |
| Solubility in water | Fully soluble (miscible) | –COOH H-bonds with water |
| Density | 1.05 g/cm³ | Slightly denser than water |
Short-chain carboxylic acids (C₁–C₄) are colourless LIQUIDS with sharp, vinegar-like smells. Higher members are oily liquids; very long-chain ones (fatty acids C₁₂+) are waxy solids.
Why higher boiling points than alkanes / alcohols of similar size.
Compare:
| Compound | bp (°C) | Reason |
|---|---|---|
| Ethanoic acid (CH₃COOH, M = 60) | 118 | Strong H-bonding via –COOH; forms cyclic dimers |
| Ethanol (CH₃CH₂OH, M = 46) | 78 | H-bonding via –OH (weaker than –COOH) |
| Propane (C₃H₈, M = 44) | –42 | Only van der Waals forces |
Carboxylic acids have the HIGHEST bp among the small organic molecules because:
- The –COOH group has BOTH the C=O (acceptor) AND O-H (donor) for hydrogen bonding.
- In pure liquid, carboxylic acid molecules form DIMERS — two molecules joined by two H-bonds in a ring:
O ─ ─ H ─ O
|| ||
CH₃ ─ C C ─ CH₃
| |
O ─ H ─ ─ O
Breaking dimers requires extra energy → higher bp.
Why soluble in water.
The –COOH group is polar and H-bonds strongly with water. Methanoic, ethanoic, propanoic, and butanoic acids are FULLY miscible with water in any ratio. Longer chains have non-polar regions that dominate → solubility decreases. C₁₀+ fatty acids are essentially insoluble in water (but soluble in non-polar solvents).
Smell + safety.
- Methanoic acid — sharp, ant-sting smell. Causes painful skin irritation (the burning sensation of an ant bite).
- Ethanoic acid — pungent, vinegar smell. At 5% (vinegar) it's safe for food; at 100% ('glacial acetic acid') it's corrosive — can burn skin.
- Propanoic acid — fruity / cheesy smell. Found in some cheeses (Swiss cheese gets its distinctive smell from propanoic acid + other carboxylic acids).
- Butanoic acid — RANCID / sweaty smell. Found in rancid butter, body odour, vomit. Powerful — detectable at very low concentrations.
The smells of foods and fragrances are heavily influenced by short-chain carboxylic acids and their esters.
Industrial production of ethanoic acid.
Two main routes:
- Bacterial oxidation of ethanol (vinegar route) — slow, low concentration, used for food vinegar.
- Catalytic carbonylation of methanol — modern industrial route. Methanol + CO → ethanoic acid, over Rh / Ir catalysts. Most pure industrial ethanoic acid is made this way.
Global ethanoic acid production: ~ 17 million tonnes/year. Major uses:
- Vinyl acetate monomer → poly(vinyl acetate) plastic (paints, adhesives).
- Cellulose acetate → photographic film, cigarette filters.
- Ethyl ethanoate solvent → nail polish, paints.
- Food additive (E260 — preservative + flavouring).
- Carboxylic acids: CₙH₂ₙ₊₁COOH, –COOH functional group.
- First three: methanoic HCOOH (ant stings), ethanoic CH₃COOH (vinegar), propanoic CH₃CH₂COOH.
- Liquids at room T, soluble in water, pungent smells.
- Higher bp than alcohols of similar mass — strong H-bonding via –COOH (dimers).
- Naming: drop '-e' from alkane stem; add '-oic acid'. Carboxyl C is counted as C1.
- Industrial uses: solvents, plastics (PVA), film, cigarette filters, food preservatives.
- Glacial ethanoic acid (100%) is CORROSIVE; vinegar (5%) is safe for food.
