Potential Dividers Study Notes — Cambridge International A Level Physics 9702 (2025-2027 syllabus)

Series resistors split voltage. Sensors via potential divider.

What you’ll learn

Mapped to the Cambridge IGCSE 9702 syllabus (2025-2027).

10.3.1 — Apply potential divider rule.
10.3.2 — Design sensor circuits.
10.3.3 — Account for loading.

Potential divider rule

Voltage splits with resistance.

Rule. PD across $R_2$ (in series with $R_1$ , across total $V$ ): $V_2 = V \frac{R_2}{R_1 + R_2}$

Same current through both $R_1$ and $R_2$ : $I = V/(R_1 + R_2)$ . So $V_2 = IR_2 = VR_2/(R_1 + R_2)$ .

Special cases.

$R_1 = R_2$ : $V_2 = V/2$ .
$R_2 \gg R_1$ : $V_2 \approx V$ (most across larger).
$R_2 \ll R_1$ : $V_2 \approx 0$ .

Example. 12 V across 4 Ω and 8 Ω: $V_8 = 12 \times 8/12 = 8$ V; $V_4 = 4$ V.

Cambridge tip. Memorise formula — saves time.

$V_2 = V R_2/(R_1 + R_2)$ .
Same current through both.
Linear in $R_2$ if $R_1$ fixed.

See the full worked example for potential dividers →

Sensor circuits

Variable $R$ → variable output.

Thermistor (NTC). Resistance DECREASES with temperature.

In divider with fixed $R$ :

Output across THERMISTOR: decreases with $T$ .
Output across FIXED resistor: increases with $T$ .

LDR (Light Dependent Resistor). Resistance DECREASES with light intensity. Similar circuit logic.

Cambridge tip. Identify which device is across the output — output behaviour follows.

Thermistor/LDR sense temperature/light.
Output depends on which $R$ is across it.
Useful for control circuits.

See the full worked example for potential dividers →

Loading effect

Voltmeter changes output.

Problem. When a load (e.g. voltmeter) is connected across part of a divider, it draws current and DECREASES the PD.

Solution. Voltmeter resistance should be MUCH GREATER than the resistance it's connected across. Ideal voltmeter: infinite resistance.

Effect. Combine voltmeter and resistor in PARALLEL; effective resistance LOWER. Output PD then lower than 'no load' case.

Example. 10 V across two 10 kΩ; voltmeter 50 kΩ reads across one.

Effective parallel: $R_p = (10 \times 50)/(60) \approx 8.33$ kΩ.
$V_{\text{read}} = 10 \times 8.33/18.33 \approx 4.55$ V (not 5 V).

Cambridge tip. Voltmeter must be 'high resistance' to give true reading.

Load reduces output.
Voltmeter must be high R.
Combine voltmeter || resistor in parallel.

See the full worked example for potential dividers →

How it’s examined

Potential dividers very common on Paper 2. Most-tested: rule (5 marks), sensor circuit (7-10 marks), loading (7 marks).

Sources: Cambridge International A Level Physics 9702 syllabus (2025-2027); 9702 Examiner Reports 2022-2024; 9702/22 May/Jun 2024 question paper and mark scheme. Last reviewed 2026-05-11.

Master this Topic

Worked examples, formulae, definitions and the mistakes examiners flag — everything you need to push from a pass to an A*.

Take this whole topic with you

Download a branded revision sheet — worked examples, formulae, definitions and common mistakes for Potential dividers, ready to print or save as PDF.

Step-by-step worked examples — Potential dividers

Step-by-step solutions to past-paper-style questions on potential dividers, written exactly the way a tutor would explain them at the board.

1Potential divider (5 marks)
Extended• Adapted from 9702/22 May/Jun 2024• potential divider
Question
A 12 V supply is connected across two resistors in series: 4 Ω and 8 Ω. Find the PD across the 8 Ω resistor. (5 marks)
Step-by-step solution
1. Step 1
  Potential divider rule. $V_2 = V \times \dfrac{R_2}{R_1 + R_2}$ .
  $V_2 = 12 \times \dfrac{8}{4 + 8} = 12 \times \dfrac{8}{12} = 8 \text{ V}$
Answer
$V = 8$ V.
2Thermistor sensor (7 marks)
Extended• thermistor
Question
A potential divider has 12 V supply, fixed 10 kΩ resistor, and thermistor in series. Thermistor at room temp = 5 kΩ. Output is the PD across the thermistor. Find output. What happens if temperature rises? (7 marks)
Step-by-step solution
1. Step 1
  Output across thermistor.
  $V_T = 12 \times \dfrac{5}{10 + 5} = 4.0 \text{ V}$
2. Step 2
  Thermistor (NTC) resistance DECREASES with temperature.
3. Step 3
  Output PD across thermistor decreases. Output proportional to $R_T/(R_1 + R_T)$ . As $R_T$ falls, this fraction falls.
Answer
Output = 4.0 V at room T. Output DECREASES as T rises.
3Loaded potential divider (8 marks)
Extended• loading
Question
Potential divider has 10 V supply and two 10 kΩ resistors. A voltmeter of 50 kΩ resistance reads across one of them. Find the actual reading. (8 marks)
Step-by-step solution
1. Step 1
  Voltmeter in parallel with 10 kΩ. Combined resistance:
  $R_p = \dfrac{10 \times 50}{10 + 50} = \dfrac{500}{60} \approx 8.33 \text{ k}\Omega$
2. Step 2
  Now divider: 10 kΩ in series with $R_p$ .
  $V_p = 10 \times \dfrac{8.33}{10 + 8.33} \approx 4.55 \text{ V}$
3. Step 3
  Voltmeter reads ~4.55 V (lower than ideal 5 V because of loading).
Answer
$V \approx 4.55$ V.
