What are the three main methods of thermal energy transfer covered in the Cambridge IGCSE Physics syllabus?

The three main methods of thermal energy transfer are conduction, convection, and radiation. Conduction occurs in solids where heat is transferred through direct contact of particles. Convection occurs in fluids (liquids and gases) where heat is transferred by the movement of the fluid itself. Radiation is the transfer of heat through electromagnetic waves and does not require a medium.

How does conduction work in the transfer of thermal energy?

Conduction is the process where thermal energy is transferred through a material without the movement of the material itself. In solids, particles are closely packed and vibrate in place. When one part of the solid is heated, its particles gain energy and vibrate more vigorously, passing on their energy to neighboring particles. This process continues throughout the material, transferring heat from the hot end to the cooler end.

Can you explain how convection currents are formed in fluids?

Convection currents are formed in fluids when a part of the fluid is heated, causing it to expand and become less dense. The less dense, warmer fluid rises, and the cooler, denser fluid sinks to take its place. This movement creates a cycle known as a convection current, which facilitates the transfer of thermal energy throughout the fluid. This process is common in both liquids and gases.

What role does radiation play in the transfer of thermal energy?

Radiation is the transfer of thermal energy through electromagnetic waves, such as infrared radiation. Unlike conduction and convection, radiation does not require a medium and can occur in a vacuum. All objects emit and absorb thermal radiation, and the amount of radiation emitted increases with the temperature of the object. This is why the Sun can transfer heat to Earth through the vacuum of space.

Why are metals generally better conductors of heat compared to non-metals?

Metals are generally better conductors of heat because they have free electrons that can move easily throughout the material. When a metal is heated, these free electrons gain kinetic energy and move rapidly, transferring energy quickly from the hot part of the metal to the cooler parts. Non-metals lack these free electrons, so they rely solely on the vibration of atoms for heat transfer, making them less efficient conductors.

Why is "Saying radiation needs a medium" a common mistake in Transfer of Thermal Energy?

Why it happens: Confusing with sound or convection. How to avoid it: EM waves (including IR) travel through a vacuum — that's how the Sun reaches us. Source: 0625/42 — recurring

Why is "Using 'convection' to explain heat through a metal rod" a common mistake in Transfer of Thermal Energy?

Why it happens: Convection is the most familiar. How to avoid it: Solids do not flow — heat in a metal rod is CONDUCTION (mainly free electrons).

Why is "Saying 'hot air rises' without mentioning density" a common mistake in Transfer of Thermal Energy?

Why it happens: Folk science. How to avoid it: Hot air rises BECAUSE it is LESS DENSE than cooler surrounding air.

Why is "Saying shiny surfaces are bad ONLY at absorbing" a common mistake in Transfer of Thermal Energy?

Why it happens: Forgetting symmetry. How to avoid it: Good absorbers are also good emitters; shiny is bad at BOTH.

Thermal PhysicsCambridge IGCSE Physics (0625)

Transfer of Thermal Energy

Work through the notes, try the practice questions, then take the quiz. The report tells you exactly what to revise next.

Previous Next

Learn this Topic

Start with the slides for the quick version, then go deeper with the full study notes.

Short Study Notes in the form of Slides

Read the notes first. If the method in a worked example clicks, you're ready for the questions.

Page 1 / 0

Detailed Notes

Full prose, callouts and a recap — built for A* mastery, not just a quick scan.

Take these study notes with you

Download a branded PDF — full prose, callouts, recap and memorise list for Transfer of Thermal Energy, ready to print or save offline.

Transfer of Thermal Energy — Cambridge IGCSE 0625 Physics Extended (2026)

Three modes of heat transfer: conduction (solids), convection (fluids), radiation (any). Plus how to reduce each — vacuum flasks are the classic example.

What you’ll learn

Mapped to the Cambridge IGCSE 0625 syllabus (2026-2028).

2.3 — Describe thermal energy transfer by conduction, convection and radiation.
2.3 — Explain conduction in metals using free electrons (Extended).
2.3 — Identify good and bad emitters/absorbers of infrared radiation.
2.3 — Explain how a vacuum flask reduces thermal energy transfer.

Conduction

Vibrations passed particle to particle. Metals are best (free electrons).

Mechanism. In solids, particles vibrate. A heated end has particles vibrating MORE. They jostle their neighbours, who jostle theirs — vibration energy passes through.

In metals (Extended). A second mechanism dominates: free (delocalised) electrons. The electrons gain KE at the hot end and travel quickly to cooler regions, transferring energy with them. This is why metals conduct heat MUCH better than non-metals.

In metals both effects work, but free electrons carrying kinetic energy make conduction much faster.

Order of conductors.

Best: metals (especially copper, aluminium).
Middling: other solids (glass, brick).
Poor: liquids, then gases (very poor — particles too far apart).
Worst: vacuum (no particles at all → no conduction).

Worked qualitative. Why does a metal handle on a saucepan get hot quickly, but a wooden one stays cool? Metal has free electrons → fast conduction. Wood has none → slow.

Conduction: particle vibrations pass on energy.
Metals: free electrons make it MUCH faster.
Liquids and gases: poor conductors.
Vacuum: no conduction at all.

Convection

Hot fluid expands, becomes less dense, rises. Cold fluid sinks. Cycle = convection current.

Mechanism (fluids only).

Heater warms a region of fluid.
The warmed region expands → density drops → it RISES (buoyancy).
Cooler, denser fluid sinks to take its place.
New fluid is heated → cycle continues.

This sets up a continuous convection current — a loop that carries heat through the fluid.

Warm, less dense fluid rises; it cools, becomes denser and sinks — a continuous circulating loop.

Worked qualitative. A radiator at the bottom of a room heats the air. Hot air rises to the ceiling, cools, sinks back down on the other side. The room warms evenly through this cycle.

Why no convection in solids. Particles can't flow → no bulk movement → no convection.

Sea breezes. During the day, land heats up faster than the sea. Air over land rises; cooler sea air rushes in to replace it. At night the reverse happens (land cools faster).

Hot fluid → less dense → rises.
Cold fluid sinks. Loop = convection current.
No convection in solids (no flow).
Sea breezes are convection at scale.

Radiation

Infrared electromagnetic waves. Needs no medium. Works through vacuum.

Thermal radiation is electromagnetic waves emitted by all warm objects, predominantly in the infrared band. Doesn't need a medium — that's how heat from the Sun reaches Earth through space.

Surface effect.

Surface	Emits	Absorbs
Black, dull	Well	Well
White, shiny	Poorly	Poorly (reflects)

Practical applications.

Solar panels (water-heating): black painted to absorb radiation effectively.
Coolant fins: black fins on the back of a fridge or radiator emit heat.
Survival blankets / Thermos flasks: silver surfaces reflect radiation back, retaining heat.

Rate of radiation depends on:

Surface temperature (hotter → more radiation).
Surface area.
Surface colour and texture.

Worked. Why are houses in hot countries painted white? White reflects most of the Sun's radiation, keeping the inside cooler.

Infrared electromagnetic waves.
No medium needed (works in vacuum).
Black dull = good emitter AND absorber.
White shiny = poor emitter, good reflector.

Vacuum flask — all three at once

Vacuum stops conduction & convection. Silvered walls reduce radiation.

A vacuum flask keeps drinks hot or cold using all three principles:

Vacuum between walls → no particles → no conduction or convection across the gap.
Silvered (reflective) walls → poor emitters / absorbers of radiation. Heat stays inside (or outside).
Stopper at the top is a thermal insulator → reduces conduction through the lid.

All three transfer modes are blocked at once — vacuum gap, silvered walls and an insulating stopper.

Even so, no flask is perfect. Heat slowly escapes (or enters) through the stopper, and the small amount of radiation that does cross the silvered walls.

Real applications. Coffee thermos, cryogenic dewars, double-glazed windows (vacuum or low-conductivity gas between panes plus reflective coatings).

Vacuum: stops conduction & convection.
Silvered walls: stop radiation.
Insulating stopper: stops conduction at top.
Same idea: double glazing.

How it’s examined

Heat transfer appears every Paper 2 (3-4 marks: identify which mode dominates) and most Paper 4s (5-6 marks: explain a vacuum flask, sea breeze, or solar panel). Examiner reports flag students writing "heat rises" — Cambridge wants "hot air rises because it is less dense".

Sources: Cambridge IGCSE Physics 0625 syllabus 2026-2028 (2.3); 0625/22 May/Jun 2024 — Q9 (vacuum flask); 0625 Examiner Reports 2022-2024. Last reviewed 2026-05-06.

Master this Topic

Worked examples, formulae, definitions and the mistakes examiners flag — everything you need to push from a pass to an A*.

Take this whole topic with you

Download a branded revision sheet — worked examples, formulae, definitions and common mistakes for Transfer of Thermal Energy, ready to print or save as PDF.

Step-by-step worked examples — Transfer of Thermal Energy

Step-by-step solutions to past-paper-style questions on transfer of thermal energy, written exactly the way a tutor would explain them at the board.

1Why metals conduct better than non-metals
Core• conduction
Question
Explain why a metal spoon feels hotter than a wooden one when both are placed in hot soup.
Step-by-step solution
1. Step 1
  Metals have FREE (delocalised) electrons that move quickly through the lattice.
2. Step 2
  Free electrons transfer kinetic energy to cooler regions much faster than vibrating atoms alone.
Answer
Metals conduct via free electrons; non-metals only via slower atomic vibration.
2Convection current in a beaker of water
Core• Adapted from 0625/22 May/Jun 2024 Q11• convection
Question
Explain how a convection current forms when water is heated from below.
Step-by-step solution
1. Step 1
  Water at the bottom warms, expands, becomes less dense.
2. Step 2
  Less dense water rises; cooler, denser water sinks to take its place.
3. Step 3
  Continual rising-and-sinking forms a convection current.
Answer
Heated water expands, becomes less dense and rises; cool water sinks → circulation current.
3Good and bad emitters
Extended• radiation
Question
Why is a teapot painted matt black better at radiating heat than one with a shiny silver finish?
Step-by-step solution
1. Step 1
  Matt black surfaces are good EMITTERS and ABSORBERS of infrared radiation.
2. Step 2
  Shiny silver surfaces are POOR emitters and absorbers (and good reflectors).
Answer
Black, dull → high IR emission. Shiny silver → low IR emission.
4Vacuum flask design
Extended• vacuum flask
Question
Explain how a vacuum flask reduces all three types of thermal energy transfer.
Step-by-step solution
1. Step 1
  Vacuum gap eliminates conduction AND convection (no particles to transfer energy).
2. Step 2
  Silvered inner walls reduce radiation by reflecting IR back inside.
3. Step 3
  Plastic stopper and outer casing reduce conduction further.
Answer
Vacuum stops conduction/convection; silvering reduces radiation; plastic limits residual conduction.
5Conduction in metals vs non-metals (particle level)
Extended• Adapted from 0625/42 May/Jun 2023 Q12• conduction, explain
Question
Compare conduction in a metal and an insulator (e.g. wood) in terms of particle behaviour.
Step-by-step solution
1. Step 1
  In all solids, atoms vibrate. Energy is transferred from hotter (faster-vibrating) atoms to cooler neighbours through the lattice — this is slow lattice conduction.
2. Step 2
  Metals additionally have free (delocalised) electrons. These move quickly through the structure, carrying KE from hot regions to cold regions much faster than lattice vibration alone.
3. Step 3
  Non-metals such as wood have NO free electrons, so only the slow lattice mechanism operates → they are poor conductors / good insulators.
Answer
Metals: fast electron-based conduction + lattice vibration. Non-metals: lattice vibration only → much slower.
Examiner tip
The examiner report flags candidates often write 'metals have more particles' or 'metals contain heat'. Marks come from naming free/delocalised electrons explicitly.
6Factors that change rate of radiation
Extended• radiation
Question
State four factors that affect how quickly an object emits infrared radiation, and for each say how an increase changes the emission.
Step-by-step solution
1. Step 1
  Surface temperature: hotter object → more IR emitted (very strong dependence on temperature).
2. Step 2
  Surface area: larger area → more IR emitted (proportional).
3. Step 3
  Surface colour: matt black → high emission; shiny silver/white → low emission.
4. Step 4
  Surface texture: dull/rough → high emission; smooth/polished → low emission.
Answer
Higher temperature, larger area, darker colour, duller texture each increase the rate of IR emission.
7Identify the dominant transfer mode
Extended• modes
Question
For each scenario, name the MAIN mode of thermal energy transfer: (a) a metal saucepan handle becoming hot, (b) warm air circulating in a room, (c) heat reaching Earth from the Sun, (d) a marshmallow held near (not in) a campfire.
Step-by-step solution
1. Step 1
  (a) Conduction along the metal — free electrons and lattice vibration.
2. Step 2
  (b) Convection — warmer air rises (less dense), cool air sinks.
3. Step 3
  (c) Radiation — EM waves through the vacuum of space.
4. Step 4
  (d) Radiation — IR from the flames travels through the air without heating it appreciably (air is a poor conductor and convection currents rise above the marshmallow).
Answer
(a) Conduction. (b) Convection. (c) Radiation. (d) Radiation.
8Black vs silver kettle cooling rates
Extended• radiation, graph
Question
Two identical kettles hold the same volume of boiling water in the same room. Kettle A is painted matt black; kettle B is highly polished silver. Sketch on the same axes how the water temperature in each kettle changes with time, and explain.
Step-by-step solution
1. Step 1
  Both kettles cool: temperature drops smoothly toward room temperature (curved, levelling off).
2. Step 2
  Matt black A is a BETTER emitter of IR radiation → loses energy faster → its curve falls more steeply, especially while hot.
3. Step 3
  Shiny silver B is a POOR emitter → cools more slowly → its curve is above A throughout.
Answer
Both curves fall toward room temperature; black-kettle curve A is below the silver-kettle curve B at all times (A cools faster).
9A* — Earth's surface temperature and the greenhouse effect
Challenge• Adapted from 0625/42 Oct/Nov 2024 Q12• synoptic, radiation
Question
Explain how the Earth's atmosphere keeps the surface warmer than it would otherwise be, in terms of incoming and outgoing radiation.
Step-by-step solution
1. Step 1
  The Sun emits short-wavelength radiation (visible/near-IR) which mostly passes through the atmosphere and is absorbed by the Earth's surface, warming it.
2. Step 2
  The Earth's surface re-emits radiation, but at a much LOWER temperature → longer-wavelength infrared.
3. Step 3
  Greenhouse gases (CO $_2$ , methane, water vapour) absorb this long-wavelength IR and re-emit it in all directions, so part of the energy is sent back toward the surface.
4. Step 4
  Less energy escapes to space → equilibrium temperature is higher than without the absorbing atmosphere.
Answer
Greenhouse gases trap long-wavelength IR re-emitted by the Earth, raising the equilibrium surface temperature.
Examiner tip
The examiner report flags candidates often say 'the atmosphere reflects the Sun's heat back' — the marking point is ABSORBS and RE-EMITS, not reflects.
10A* — Loft insulation synoptic
Challenge• synoptic
Question
A house owner adds a layer of fibreglass loft insulation. (a) Which mechanism does it primarily reduce, and how? (b) The owner also fits foil-backed boards under the roof tiles. Which mechanism does the foil mainly reduce? (c) Explain why thick double-glazing reduces heat loss through windows more than a single sheet of glass of the same total thickness.
Step-by-step solution
1. Step 1
  (a) Fibreglass traps small air pockets. Air is a poor conductor and the trapped pockets stop convection currents forming → reduces convection AND conduction through the ceiling.
2. Step 2
  (b) Foil is a shiny surface → poor emitter and good reflector of IR → reflects radiation back into the loft, reducing radiative loss.
3. Step 3
  (c) Double-glazing has a sealed air (or argon) gap between two thin panes. The trapped gas is a poor conductor, and the small gap suppresses convection. A single thick glass sheet still conducts through its full thickness — glass is a much better conductor than air.
Answer
(a) Fibreglass: conduction and convection (trapped air). (b) Foil: radiation (poor emitter, reflects IR). (c) Double-glazing uses a trapped-gas gap that is a worse conductor than glass, while solid glass conducts throughout its thickness.

Key Formulae — Transfer of Thermal Energy

The formulae you need to memorise for transfer of thermal energy on the Cambridge IGCSE 0625 paper, with every variable defined in plain English and a note on when to use it.

Three mechanisms of heat transfer
$\text{Conduction} \rightarrow \text{solids};\ \text{Convection} \rightarrow \text{fluids};\ \text{Radiation} \rightarrow \text{any}$
When to use
Identifying which mode applies in a question.

Key Definitions and Keywords — Transfer of Thermal Energy

Definitions to memorise and the exact keywords mark schemes credit for transfer of thermal energy answers — sharpened from recent examiner reports for the 2026 0625 sitting.

Conduction
Examiner keyword
Transfer of thermal energy through a material WITHOUT bulk movement of the material. Mainly via lattice vibration; in metals, via free electrons.
Convection
Examiner keyword
Transfer of thermal energy in a fluid by bulk movement of warmer, less-dense regions of the fluid.
Infrared radiation
Examiner keyword
Transfer of thermal energy by electromagnetic waves; requires no medium.
Good emitter / absorber
Examiner keyword
Matt black surfaces emit and absorb IR well; shiny silver surfaces are poor at both (good reflectors).

Common Mistakes and Misconceptions — Transfer of Thermal Energy

The traps other students keep falling into on transfer of thermal energy questions — taken from recent Cambridge IGCSE 0625 examiner reports and mark schemes — and how to avoid them.

✕Saying radiation needs a medium
0625/42 — recurring
Why it happens
Confusing with sound or convection.
How to avoid it
EM waves (including IR) travel through a vacuum — that's how the Sun reaches us.
✕Using 'convection' to explain heat through a metal rod
Why it happens
Convection is the most familiar.
How to avoid it
Solids do not flow — heat in a metal rod is CONDUCTION (mainly free electrons).
✕Saying 'hot air rises' without mentioning density
Why it happens
Folk science.
How to avoid it
Hot air rises BECAUSE it is LESS DENSE than cooler surrounding air.
✕Saying shiny surfaces are bad ONLY at absorbing
Why it happens
Forgetting symmetry.
How to avoid it
Good absorbers are also good emitters; shiny is bad at BOTH.

Practice questions

Exam-style questions with step-by-step worked solutions. Try one before checking the method.

Past paper style quiz

Get a report showing which sub-topics you've nailed and which ones still need work.

Video lesson

Short walkthrough of the concepts students most often get stuck on.

Transfer of Thermal Energy — frequently asked questions

The things students keep getting wrong in this sub-topic, answered.

Transfer of Thermal Energy

Short Study Notes in the form of Slides

Detailed Notes

What you’ll learn

How it’s examined

1Why metals conduct better than non-metals

2Convection current in a beaker of water

3Good and bad emitters

4Vacuum flask design

5Conduction in metals vs non-metals (particle level)

6Factors that change rate of radiation

7Identify the dominant transfer mode

8Black vs silver kettle cooling rates

9A* — Earth's surface temperature and the greenhouse effect

10A* — Loft insulation synoptic

Three mechanisms of heat transfer

Conduction

Convection

Infrared radiation

Good emitter / absorber

✕Saying radiation needs a medium

✕Using 'convection' to explain heat through a metal rod

✕Saying 'hot air rises' without mentioning density

✕Saying shiny surfaces are bad ONLY at absorbing

Practice questions

Past paper style quiz

Assess your understanding

Video lesson

Transfer of Thermal Energy — frequently asked questions
