Detailed notes on Motion, Forces and Energy for Cambridge IGCSE Physics, covering key concepts, explanations, examples, and exam-focused revision points.
p=mv as a vector. Conservation of momentum in collisions and explosions, plus Newton's second law in its momentum form: F=Δp/Δt.
At a glance
Momentump=mv. Vector. Units: kg m/s.
Conservation: total momentum before = total momentum after (closed system).
Force = rate of change of momentum: F=Δp/Δt.
Impulse = FΔt=Δp.
Direction matters — choose a positive direction and stick to it.
Crumple zones, airbags, helmets all increase Δt to reduce F.
What you’ll learn
Mapped to the Cambridge IGCSE 0625 syllabus (2026-2028).
1.6 — Define momentum as p=mv.
1.6 — State and apply the principle of conservation of momentum to collisions in one dimension.
1.6 — Apply F=Δp/Δt to calculate force in a collision.
Defining momentum
p=mv. Vector. Sign matches direction.
Momentum.p=mv.
p: momentum (kg m/s).
m: mass (kg).
v: velocity (m/s).
Vector. Direction matters — momentum to the LEFT is the negative of momentum to the RIGHT.
Worked. A 0.5kg ball at 4m/s.
p=0.5×4=2kg m/s.
Worked. Same ball, now at 4m/s in the OPPOSITE direction.
p=−2kg m/s (taking original direction as positive).
p=mv.
Vector — choose +ve direction and stick to it.
Units: kg m/s.
Conservation of momentum
In any closed system (no external force), total momentum before = total momentum after.
Principle.pbefore, total=pafter, total.
Applies to collisions and explosions.
Worked (collision). A 2kg trolley at 3m/s collides with a stationary 1kg trolley. They stick. Find their common velocity.
Before: p=2×3+1×0=6kg m/s.
After: (2+1)×v=6⇒v=2m/s.
Worked (explosion). A stationary cannon (500kg) fires a 5kg shell at 200m/s. Find recoil velocity.
Before: p=0.
After: 5×200+500×vcannon=0.
vcannon=−1000/500=−2m/s (recoils opposite to shell).
Tip. Always set up "before" and "after" rows and equate. Direction signs matter.
In a closed system, the total momentum is the same before and after the collision.
Total p conserved in closed system.
Set up before-after table.
Watch direction signs.
Works for collisions AND explosions.
Force as rate of change of momentum
F=Δp/Δt. The original form of Newton's second law.
Newton's second law (momentum form).F=ΔtΔp=Δtm(v−u).
This is identical to F=ma when mass is constant.
Worked. A 0.05kg tennis ball at 20m/s is hit back at 25m/s. Contact time 0.005s.
Δp=m(v−u)=0.05×(−25−20)=−2.25kg m/s (taking incoming direction as positive).
∣F∣=2.25/0.005=450N.
Impulse.FΔt=Δp. Same idea, rearranged.
Safety applications. Crumple zones, airbags, helmets, sand pits all INCREASE the time over which momentum changes, REDUCING the force on the body.
The same change in momentum spread over a longer time means a much smaller peak force.
F=Δp/Δt.
Impulse =FΔt=Δp.
Increase Δt → reduce F for same Δp.
Safety devices apply this idea.
Quick recap
p=mv. Vector.
Conservation: total p before = after.
F=Δp/Δt.
Impulse =FΔt=Δp.
Safety devices increase Δt to reduce F.
Memorise this
Verbatim phrases and definitions Cambridge mark schemes credit.
Momentum — product of mass and velocity, vector.
Conservation of momentum — total momentum is constant in a closed system.
Impulse — product of force and time of application, equals change in momentum.
How it’s examined
Momentum appears every Paper 4 (5-7 marks) — a collision-conservation calculation followed by a F=Δp/Δt part on a safety device. Examiner reports flag two errors: missing negative sign for opposite direction, and using mass instead of momentum in the conservation equation.
Step-by-step solutions to past-paper-style questions on momentum, written exactly the way a tutor would explain them at the board.
Question type:
Question patterns to master — Momentum
Almost every momentum exam question is one of these shapes. Learn to spot each one and you will always know how to start.
Direct calculation▼
Recognise it by
A single calculate or find instruction using one momentum formula — p=mv, impulse =Ft, or conservation m1u1+m2u2=m1v1+m2v2.
How to approach it
Choose a positive direction first, write the formula, substitute with signed velocities, then give the answer with its unit (kg m/s for momentum, N s for impulse).
Common trap
Examiner reports flag candidates forgetting to reverse the sign of a velocity after a rebound — momentum is a vector, so direction matters.
Multi-step problem▼
Recognise it by
Several stages are chained — two scenarios compared, or conservation of momentum followed by a kinetic-energy check.
How to approach it
Work each stage in turn with a clear sub-answer, keeping the same positive direction throughout; only combine the results at the end.
Common trap
Assuming kinetic energy is conserved. Momentum is always conserved in a closed system, but kinetic energy is conserved only in an elastic collision.
1Calculate momentum
CoreDirect calculation• p=mv
▼
Question
A 1500kg car moves at 20m/s. Find its momentum.
Step-by-step solution
Step 1
p=mv.
p=1500×20=30,000kgm/s
Answer
30,000kgm/s
2Impulse and change in momentum
ExtendedDirect calculation• Adapted from 0625/42 May/Jun 2024 Q6• impulse
▼
Question
A 0.4kg ball travels at 5m/s and rebounds elastically off a wall at 5m/s in the opposite direction. Find the impulse.
Step-by-step solution
Step 1
Take initial direction as positive.
Δp=mv−mu=0.4(−5)−0.4(5)=−4kgm/s
Step 2
Magnitude of impulse.
∣impulse∣=4kgm/s=4Ns
Answer
4Ns (directed away from the wall)
Examiner tip
Don't forget the sign change — initial and final velocities are in opposite directions.
3Conservation in a collision
ExtendedDirect calculation• conservation
▼
Question
A 2kg trolley moving at 3m/s collides with a stationary 1kg trolley. They stick. Find the velocity after.
Step-by-step solution
Step 1
Total momentum before = total after.
(2)(3)+(1)(0)=(2+1)v
Step 2
Solve.
v=36=2m/s
Answer
2m/s in the same direction
4Average force from change in momentum
ExtendedDirect calculation• F=Δp/t
▼
Question
A 0.05kg tennis ball arrives at 30m/s and leaves at 40m/s in the opposite direction after 0.01s of contact. Find the average force.
Step-by-step solution
Step 1
Change in momentum.
Δp=0.05(−40)−0.05(30)=−3.5kgm/s
Step 2
Average force.
F=t∣Δp∣=0.013.5=350N
Answer
350N
5Momentum from mass and speed
CoreDirect calculation• p=mv
▼
Question
Compare the momenta of (a) a 50kg runner at 8m/s and (b) a 4000kg truck at 0.10m/s.
Step-by-step solution
Step 1
Runner.
pr=50×8=400kgm/s
Step 2
Truck.
pt=4000×0.10=400kgm/s
Answer
Both have momentum 400kgm/s — equal, despite very different masses and speeds.
6Change in momentum: bouncing vs sticking
ExtendedMulti-step problem• Adapted from 0625/22 May/Jun 2024 Q12• change in p
▼
Question
A 0.20kg ball arrives at a wall at 6m/s. Find the change in its momentum if it (a) sticks to the wall, (b) rebounds elastically at 6m/s.
Step-by-step solution
Step 1
Take initial direction toward the wall as positive.
Step 2
(a) Sticks: final v=0.
Δpa=0.20(0)−0.20(6)=−1.2kgm/s
Step 3
(b) Rebounds elastically: final v=−6.
Δpb=0.20(−6)−0.20(6)=−2.4kgm/s
Answer
(a) ∣Δp∣=1.2kgm/s. (b) ∣Δp∣=2.4kgm/s — twice as much.
Examiner tip
The examiner report flags candidates often quote Δp=0 for the elastic case because 'the speed is the same'. The DIRECTION changes, so the change in momentum is the largest — that's why bouncing is harder on the wall than sticking.
7Recoil — conservation in an 'explosion'
ExtendedDirect calculation• recoil, conservation
▼
Question
A 4.0kg rifle fires a 0.020kg bullet at 300m/s. Find the recoil velocity of the rifle.
Step-by-step solution
Step 1
Before firing, total momentum is zero (both at rest). By conservation, total after is also zero.
0=mrvr+mbvb
Step 2
Solve for vr.
vr=−mrmbvb=−4.00.020×300
Step 3
Evaluate.
vr=−1.5m/s
Answer
1.5m/s in the opposite direction to the bullet.
Examiner tip
The 2024 mark scheme awards method marks for explicitly stating that initial total momentum is zero — that is the entry point to the conservation argument.
8Impulse — why airbags reduce force
ExtendedMulti-step problem• impulse, concept
▼
Question
A 60kg driver moving at 15m/s is brought to rest in a crash. Find the average force (a) over 0.05s (no airbag, hits steering wheel) and (b) over 0.30s (with airbag).
Step-by-step solution
Step 1
Change in momentum is the same in both cases.
Δp=60×15=900kgm/s
Step 2
(a) No airbag.
Fa=0.05900=18,000N
Step 3
(b) With airbag.
Fb=0.30900=3000N
Answer
Fa=18,000N; Fb=3000N. The airbag reduces the force by a factor of 6 by extending the stopping time.
Examiner tip
The examiner report flags candidates often say the airbag 'absorbs momentum'. The momentum CHANGE is the same; the airbag spreads it over a longer time, so F=Δp/t is smaller.
9Two-car head-on collision — solve for unknown final velocity
ExtendedDirect calculation• conservation
▼
Question
A 1200kg car moving east at 8m/s collides head-on with a 800kg car moving west at 5m/s. After the collision the heavier car continues east at 2m/s. Find the final velocity of the lighter car.
Step-by-step solution
Step 1
Take east as positive. Apply conservation of momentum.
m1u1+m2u2=m1v1+m2v2
Step 2
Substitute (west = negative).
1200(8)+800(−5)=1200(2)+800v2
Step 3
Simplify left and right sides.
9600−4000=2400+800v2
Step 4
Solve.
v2=8005600−2400=4m/s east
Answer
4m/s eastward — the lighter car is knocked backwards (it was originally going west).
Examiner tip
The examiner report flags candidates often drop the sign on the lighter car's initial velocity and get an unphysical answer. Always pick a positive direction at the start.
10A* — momentum AND energy together (inelastic collision)
ChallengeMulti-step problem• synoptic, KE
▼
Question
A 3.0kg trolley moving at 4.0m/s collides with a stationary 1.0kg trolley and they stick. Find (a) the final velocity, (b) the kinetic energy before and after, and (c) state whether the collision is elastic or inelastic.
Step-by-step solution
Step 1
Conservation of momentum.
(3.0)(4.0)+(1.0)(0)=(3.0+1.0)v
Step 2
Solve.
v=4.012=3.0m/s
Step 3
KE before (only the moving trolley).
Ek,i=21(3.0)(4.0)2=24J
Step 4
KE after.
Ek,f=21(4.0)(3.0)2=18J
Step 5
KE decreased by 6J even though momentum is conserved → inelastic collision (energy transferred to heat/sound/deformation).
Answer
(a) v=3.0m/s. (b) KE before =24J, after =18J. (c) Inelastic — 6J of KE is transferred to other stores.
Examiner tip
The 2024 mark scheme awards an extra mark for stating that momentum is ALWAYS conserved in a closed system, but KE is only conserved in ELASTIC collisions.
Model Answers — Momentum
High-scoring sample answers for momentum on the Cambridge IGCSE 0625 paper, with examiner-style notes mapping each response to the mark scheme and assessment objectives.
Question 1
Paper 2/4 short-answer style1 mark
Define momentum and state its SI unit.
Model answer
Momentum is mass × velocity (p=mv). It is a vector quantity, and its SI unit is the kilogram metre per second, kgm/s (equivalently Ns).
Why this scores
One mark for 'mass × velocity' together with the unit. Because velocity is a vector, momentum is a vector — useful to state when the next part involves a collision.
Question 2
Paper 2/4 style2 marks
Calculate the momentum of a 900kg car travelling at 15m/s.
Model answer
p=mv=900×15=13500kgm/s.
Why this scores
One mark for substitution into p=mv, one for the value with the correct unit kgm/s.
Question 3
Paper 4 structured style3 marks
A 2.0kg trolley moving at 3.0m/s collides with a stationary 1.0kg trolley and they stick together. State the principle of conservation of momentum and calculate their common velocity after the collision.
Model answer
Principle: in a closed system (no external resultant force), the total momentum before a collision equals the total momentum after.
Momentum before =(2.0×3.0)+(1.0×0)=6.0kgm/s. After sticking, the combined mass is 3.0kg moving at v:
6.0=(2.0+1.0)v⟹v=3.06.0=2.0m/s
in the same direction as the original motion.
Why this scores
Three marks: statement of conservation (1), correct total momentum before with combined mass after (1), and v=2.0m/s (1). 'Stick together' means a single combined mass of 3.0kg — forgetting to add the masses is the usual slip.
Question 4
Paper 4 structured style4 marks
A 0.16kg cricket ball travelling at 25m/s is caught and brought to rest in 0.10s. (a) Calculate the change in momentum. (b) Calculate the average force the fielder's hands exert on the ball.
Model answer
(a) Change in momentum =mv−mu=(0.16×0)−(0.16×25)=−4.0kgm/s, i.e. a magnitude of 4.0kgm/s (directed opposite to the ball's motion).
(b) Average force =timechange in momentum=0.104.0=40N.
Why this scores
Four marks: change in momentum magnitude 4.0kgm/s (1) with a sign/direction comment (1); use of F=Δp/t (1); 40N (1). This links to why a fielder 'gives' with the catch — a longer time means a smaller force.
Question 5
Paper 4 application style5 marks
A car has a 70kg driver moving at 20m/s. In a crash the driver is brought to rest. Explain, with a calculation, why an airbag that increases the stopping time from 0.10s to 0.50s reduces the force on the driver.
Model answer
The driver's change in momentum is the same in both cases, because the driver goes from 20m/s to rest regardless of how they are stopped:
Δp=70×20=1400kgm/s.
The force is F=tΔp, so spreading the same momentum change over a longer time gives a smaller force:
Without airbag: F=0.101400=14000N
With airbag: F=0.501400=2800N
The airbag extends the stopping time, so for the same change in momentum the average force is reduced (here by a factor of 5), reducing the risk of injury.
Why this scores
Five marks: change in momentum is the same (1) and its value (1); F=Δp/t (1); both force values (1); conclusion that a longer time gives a smaller force (1). The airbag does not 'absorb the momentum' — the momentum change is unchanged; only the time over which it happens increases.
Question 6
Paper 4 multi-part structured style6 marks
A 2.0kg trolley moving at 6.0m/s collides with a stationary 4.0kg trolley and they move off together. (a) Calculate their common velocity. (b) Calculate the total kinetic energy before and after the collision. (c) State, with a reason, whether the collision is elastic or inelastic.
Model answer
(a) Conservation of momentum: (2.0×6.0)+(4.0×0)=(2.0+4.0)v, so 12=6.0v and v=2.0m/s.
(b) KE before =21(2.0)(6.0)2=36J. KE after =21(6.0)(2.0)2=12J.
(c) The collision is inelastic: kinetic energy has fallen from 36J to 12J — 24J has been transferred to other stores (heat, sound and deformation). Momentum is conserved in every collision, but kinetic energy is conserved only in an elastic collision.
Why this scores
Six marks: common velocity by conservation (1); KE before (1); KE after (1); identifying it as inelastic (1); KE is not conserved / energy transferred to heat etc. (1); the general statement that momentum is always conserved but KE only in elastic collisions (1).
Key Formulae — Momentum
The formulae you need to memorise for momentum on the Cambridge IGCSE 0625 paper, with every variable defined in plain English and a note on when to use it.
Momentum
p=mv
p
momentum (kg m/s)
m
mass (kg)
v
velocity (m/s)
When to use
Any moving object; vector quantity.
Impulse / change in momentum
Impulse=Ft=Δp=mv−mu
F
average force in N
t
contact time in s
When to use
Collisions where you know the contact time, or to relate force to velocity change.
Conservation of momentum
m1u1+m2u2=m1v1+m2v2
When to use
Collisions/explosions in a closed system (no external forces).
Key Definitions and Keywords — Momentum
Definitions to memorise and the exact keywords mark schemes credit for momentum answers — sharpened from recent examiner reports for the 2026 0625 sitting.
Momentum
Examiner keyword
Mass × velocity. Vector; SI unit kg m/s.
Impulse
Examiner keyword
The change in momentum produced by a force. Equal to F×t.
Principle of conservation of momentum
Examiner keyword
In a closed system the total momentum before equals the total momentum after.
Common Mistakes and Misconceptions — Momentum
The traps other students keep falling into on momentum questions — taken from recent Cambridge IGCSE 0625 examiner reports and mark schemes — and how to avoid them.
✕Adding instead of subtracting after a rebound
0625/42 — recurring
▼
Why it happens
Forgetting that velocity reverses direction.
How to avoid it
Pick a positive direction at the start. Reversed velocity gets a negative sign.
✕Quoting impulse in kg only
▼
Why it happens
Forgetting the velocity factor.
How to avoid it
Impulse has units N s = kg m/s. Always include both parts.
✕Using separate final velocities when the objects stick together
▼
Why it happens
Misreading the question.
How to avoid it
Stuck after collision → both move with the SAME final velocity. Bounce → separate finals.
✕Forgetting to add masses in 'stick together' collisions
▼
Why it happens
Treating the new combined object as having only the moving mass.
How to avoid it
After sticking, total mass = m1+m2.
Momentum — frequently asked questions
The things students keep getting wrong in this sub-topic, answered.
