StatisticsCambridge IGCSE Maths 0580 Extended

Statistical Charts and Diagrams

Work through the notes, try the practice questions, then take the quiz. The report tells you exactly what to revise next.

Previous Next

Learn this Topic

Start with the slides for the quick version, then go deeper with the full study notes.

Short Study Notes in the form of Slides

Read the notes first. If the method in a worked example clicks, you're ready for the questions.

Short Study Notes — Statistical Charts and Diagrams

Start with these resources to cover the key concepts, then work through the practice questions.

Page 1 / 0

Detailed Notes

Full prose, callouts and a recap — built for A* mastery, not just a quick scan.

Take these study notes with you

Download a branded PDF — full prose, callouts, recap and memorise list for Statistical Charts and Diagrams, ready to print or save offline.

Bar Charts, Pie Charts, Pictograms and Histograms — Cambridge IGCSE 0580 Maths Extended (2026)

Display and interpret data with the right chart for the data type. Cambridge tests construction (drawing) AND interpretation (reading values, comparing). Histograms are special — frequency DENSITY, not frequency.

What you’ll learn

Mapped to the Cambridge IGCSE 0580 syllabus (2025-2027).

E11.8 — Construct and interpret bar charts, pie charts, pictograms.
E11.9 — Construct and interpret histograms with equal and unequal class widths using frequency density.

Bar chart

Bars of equal width, separated by gaps. Height = frequency. For DISCRETE or categorical data.

Use for. Discrete or categorical data — number of pets, favourite subject, day of the week.

Rules.

Bars equal width.
Bars SEPARATED by small gaps (because data is discrete).
Height = frequency.
Label both axes; title the chart.

Multi-bar charts. For comparing two categories side-by-side (e.g. boys' vs girls' favourite subjects), draw paired bars with a key.

Worked. Survey of $50$ students' favourite sport: football $20$ , tennis $15$ , cricket $10$ , swimming $5$ .

Four bars of equal width, heights $20, 15, 10, 5$ .
Gaps between bars.
$y$ -axis labelled "Frequency", $x$ -axis labelled "Sport".

Equal-width bars with gaps — bar height reads off the frequency.

Discrete / categorical data.
Bars equal width, with gaps.
Height = frequency.
Label axes and title.

Pie chart

Angle of each sector $= \dfrac{\text{frequency}}{\text{total}} \times 360\degree$ .

Use for. Showing how a whole is split into proportions.

Construction.

Compute the total frequency.
Each category's angle: $\theta = \dfrac{f}{\text{total}} \times 360\degree$ .
Draw a circle. Use a protractor to mark each angle.
Label each sector with the category and (optionally) the angle or percentage.

Worked. Same survey: football $20$ , tennis $15$ , cricket $10$ , swimming $5$ . Total $50$ .

Football: $\dfrac{20}{50} \times 360 = 144\degree$ .
Tennis: $\dfrac{15}{50} \times 360 = 108\degree$ .
Cricket: $\dfrac{10}{50} \times 360 = 72\degree$ .
Swimming: $\dfrac{5}{50} \times 360 = 36\degree$ .
Check: $144 + 108 + 72 + 36 = 360\degree$ . ✓

Each sector angle is proportional to its frequency; all angles sum to 360°.

Reading a pie chart. If you know the total and the angle, the frequency is $\dfrac{\theta}{360} \times \text{total}$ .

Cambridge tip. Mark schemes credit a clear angle calculation table — even if the drawing is rough.

Angle $= \dfrac{f}{\text{total}} \times 360\degree$ .
All angles must sum to $360\degree$ .
Reading: $f = \dfrac{\theta}{360} \times \text{total}$ .
Show the angle table as working.

Pictogram

A symbol represents a fixed number of items. Key required.

Use for. Visually appealing, easy-to-grasp summaries — especially when numbers are small or for younger audiences.

Rules.

Each symbol represents a fixed number (the key).
Half-symbols (or quarters) represent fractions of the key value.
KEY MUST BE SHOWN.

Worked. Pictogram of class books read this term, where each book symbol $= 4$ books:

Anna: $\bigstar \bigstar \bigstar = 12$ books.
Ben: $\bigstar \bigstar \frac{1}{2}\bigstar = 10$ books.
Carol: $\bigstar \bigstar \bigstar \bigstar = 16$ books.

Reading. Multiply the number of full symbols (plus fractions) by the key value.

Cambridge tip. Always SHOW the key — Cambridge mark schemes deduct for missing keys.

One symbol = fixed number (the key).
Half-symbol = half the key value.
Key must be drawn / labelled.

Histogram (with frequency density)

Bar AREA $=$ frequency. Use FREQUENCY DENSITY ( $f /$ class width) when class widths are unequal.

Use for. Continuous data, especially with UNEQUAL class widths.

Key formula. $\text{frequency density} = \dfrac{\text{frequency}}{\text{class width}}.$

The HEIGHT of each bar is frequency density. The AREA of each bar (= height $\times$ width) equals the frequency.

Why? With unequal class widths, plotting frequency directly would mislead — a wide-class bar would look more important than it is. Frequency density corrects for the width.

Worked. Times to complete a task (minutes):

Class	Frequency $f$	Width	Frequency density
$0 < t \le 10$	8	10	0.8
$10 < t \le 20$	14	10	1.4
$20 < t \le 40$	16	20	0.8
$40 < t \le 60$	12	20	0.6

Heights: $0.8, 1.4, 0.8, 0.6$ .
Note: the third class has the SAME frequency density as the first ( $0.8$ ) but contains TWICE as many people ( $16$ vs $8$ ). This is the point of frequency density — width matters.

Reading a histogram. The frequency in any class equals (height $\times$ width). To find the number of values in a partial class (e.g. $15 < t \le 25$ ), compute the area of the relevant rectangle slice.

No gaps. Bars in a histogram TOUCH (because data is continuous). Bar charts have gaps; histograms don't.

Height is frequency density, so bar AREA gives the frequency — the wide 20–40 bar holds 16 even though it is no taller than the 0–10 bar.

Continuous data.
Frequency density $= f /$ class width.
Height = frequency density; AREA = frequency.
Bars touch (no gaps).
Use when class widths are UNEQUAL.

Which chart for which data?

Discrete + categories: bar. Proportions of a whole: pie. Continuous: histogram. Visual / informal: pictogram.

Data type	Best chart
Discrete or categorical	Bar chart
Showing proportions of a whole	Pie chart
Continuous, equal class widths	Histogram (or frequency polygon)
Continuous, unequal class widths	Histogram with frequency density
Informal / friendly	Pictogram
Compare a few small numbers	Bar chart

Cambridge questions. Often ask "what type of chart is most suitable" — answer with the data TYPE (discrete vs continuous, equal vs unequal widths) as the justification.

Discrete / categorical: bar chart.
Proportions: pie chart.
Continuous, unequal widths: histogram.
Visual / informal: pictogram.

How it’s examined

Statistical charts appear most years — Paper 2 (3-5 marks: read or construct a simple chart) and Paper 4 (5-7 marks: histogram with frequency density and unequal widths). Examiner reports flag two errors: (i) plotting frequency instead of frequency density on a histogram when widths are unequal, (ii) angles in a pie chart not summing to $360\degree$ .

Sources: Cambridge IGCSE Mathematics 0580 syllabus 2025-2027 (E11.8-11.9); 0580/42 Oct/Nov 2024 — Q18 (histogram, unequal widths); 0580 Examiner Reports 2022-2024. Last reviewed 2026-05-05.

Master this Topic

Worked examples, formulae, definitions and the mistakes examiners flag — everything you need to push from a pass to an A*.

Take this whole topic with you

Download a branded revision sheet — worked examples, formulae, definitions and common mistakes for Statistical Charts and Diagrams, ready to print or save as PDF.

Step-by-step worked examples — Statistical Charts and Diagrams

Step-by-step solutions to past-paper-style questions on statistical charts and diagrams, written exactly the way a tutor would explain them at the board.

1Construct a pie chart
Core• pie chart
Question
$30$ students chose a sport: football $12$ , tennis $9$ , hockey $6$ , swimming $3$ . Find the angle for each sector.
Step-by-step solution
1. Step 1
  Each frequency $\to$ angle $= \dfrac{\text{freq}}{\text{total}} \times 360\degree$ .
2. Step 2
  Compute.
  $F: \dfrac{12}{30} \times 360 = 144\degree;\ T: 108\degree;\ H: 72\degree;\ S: 36\degree$
Answer
$144\degree, 108\degree, 72\degree, 36\degree$
2Histogram with unequal classes
Extended• Adapted from 0580/42 May/Jun 2024 Q13• histogram
Question
Frequency table: $[0, 10) = 8$ , $[10, 25) = 18$ , $[25, 30) = 7$ . Find the frequency densities.
Step-by-step solution
1. Step 1
  $\text{FD} = \dfrac{\text{frequency}}{\text{class width}}$ .
2. Step 2
  Compute each.
  $\dfrac{8}{10} = 0.8;\ \dfrac{18}{15} = 1.2;\ \dfrac{7}{5} = 1.4$
Answer
FDs: $0.8,\ 1.2,\ 1.4$ .
Examiner tip
Histogram bars use frequency DENSITY on the y-axis (not frequency) when class widths are unequal.
3Read a box-and-whisker plot
Extended• box plot
Question
A box plot shows: min $4$ , $Q_{1} = 7$ , median $10$ , $Q_{3} = 14$ , max $20$ . State the median, range, and IQR.
Step-by-step solution
1. Step 1
  Direct reads.
  $\text{median} = 10,\ \text{range} = 20 - 4 = 16,\ \text{IQR} = 14 - 7 = 7$
Answer
Median $10$ , range $16$ , IQR $7$ .
4Compare two bar charts
Extended• bar chart
Question
Compare the heights of pupils in two classes shown by two bar charts.
Step-by-step solution
1. Step 1
  Compare modal classes, ranges, or central tendency.
Answer
Use direct reads from the charts to comment on most-common heights and spread.
5Read frequencies from a bar chart
Core• Adapted from 0580/12 May/Jun 2023 Q8• bar chart, read
Question
A bar chart shows the number of books read by $25$ students last month: $0$ books $\to 4$ , $1$ book $\to 8$ , $2$ books $\to 7$ , $3$ books $\to 4$ , $4$ books $\to 2$ . State the modal number of books and the total number of books read.
Step-by-step solution
1. Step 1
  Modal = bar with greatest frequency. Highest bar is at $1$ book ( $8$ students).
2. Step 2
  Total books = $\sum fx$ .
  $0(4) + 1(8) + 2(7) + 3(4) + 4(2) = 0 + 8 + 14 + 12 + 8 = 42$
Answer
Mode $= 1$ book; total $= 42$ books read.
6Compare data with a dual bar chart
Core• dual bar
Question
A dual bar chart shows favourite drinks for $30$ boys and $30$ girls. Boys: tea $5$ , coffee $10$ , juice $15$ . Girls: tea $12$ , coffee $6$ , juice $12$ . State which drink shows the biggest difference between boys and girls, and give that difference.
Step-by-step solution
1. Step 1
  Compute each pairwise difference: tea $|12-5| = 7$ , coffee $|10-6| = 4$ , juice $|15-12| = 3$ .
2. Step 2
  Biggest difference is for tea.
Answer
Tea, with a difference of $7$ students.
7Draw a frequency polygon
Extended• frequency polygon
Question
Frequency table of test marks: $[0, 10) = 3$ , $[10, 20) = 8$ , $[20, 30) = 12$ , $[30, 40) = 5$ . Describe the points you would plot on a frequency polygon.
Step-by-step solution
1. Step 1
  Plot frequency against the MIDPOINT of each class.
2. Step 2
  Midpoints: $5, 15, 25, 35$ . Points: $(5, 3),\ (15, 8),\ (25, 12),\ (35, 5)$ .
3. Step 3
  Join the points with straight line segments.
Answer
Plot $(5, 3), (15, 8), (25, 12), (35, 5)$ and join with straight lines.
Examiner tip
The examiner report flags candidates who plot against the lower (or upper) class boundary instead of the midpoint, losing the accuracy mark.
8Histogram with equal class widths
Extended• histogram, equal width
Question
Frequency table: $[0, 5) = 4$ , $[5, 10) = 9$ , $[10, 15) = 12$ , $[15, 20) = 7$ , $[20, 25) = 3$ . Each class has width $5$ . State the heights of the histogram bars if (a) frequency is on the y-axis, (b) frequency density is on the y-axis.
Step-by-step solution
1. Step 1
  (a) With equal class widths, frequency on the y-axis is acceptable. Heights: $4, 9, 12, 7, 3$ .
2. Step 2
  (b) Frequency density $= \dfrac{\text{frequency}}{\text{class width}}$ . Divide each by $5$ .
  $\text{FD: } 0.8, 1.8, 2.4, 1.4, 0.6$
Answer
(a) Heights $= 4, 9, 12, 7, 3$ . (b) FDs $= 0.8, 1.8, 2.4, 1.4, 0.6$ .
9Read frequency from a histogram with unequal widths (Challenge)
Challenge• Adapted from 0580/42 Oct/Nov 2024 Q11• histogram, unequal, challenge
Question
A histogram has class $[0, 20)$ with frequency density $0.6$ , class $[20, 30)$ with FD $1.5$ , class $[30, 60)$ with FD $0.4$ . Find (a) the frequency in each class, and (b) the total number of data points.
Step-by-step solution
1. Step 1
  Frequency $= \text{FD} \times \text{class width}$ .
2. Step 2
  Class $[0, 20)$ : width $20$ .
  $f = 0.6 \times 20 = 12$
3. Step 3
  Class $[20, 30)$ : width $10$ .
  $f = 1.5 \times 10 = 15$
4. Step 4
  Class $[30, 60)$ : width $30$ .
  $f = 0.4 \times 30 = 12$
5. Step 5
  Total.
  $12 + 15 + 12 = 39$
Answer
(a) $12,\ 15,\ 12$ . (b) $39$ data points.
Examiner tip
This is a classic A* trap. The examiner report consistently flags students who multiply by ' $1$ ' (treating FD as frequency) or who use the wrong class width. AREA of the bar = frequency.

Key Formulae — Statistical Charts and Diagrams

The formulae you need to memorise for statistical charts and diagrams on the Cambridge IGCSE 0580 paper, with every variable defined in plain English and a note on when to use it.

Pie chart sector angle
$\text{angle} = \dfrac{\text{frequency}}{\text{total}} \times 360\degree$
When to use
Constructing a pie chart.
Frequency density
$\text{FD} = \dfrac{\text{frequency}}{\text{class width}}$
When to use
Histograms with unequal class widths.
Frequency from area
$\text{frequency} = \text{FD} \times \text{class width}$
When to use
Reading a frequency from a histogram bar.

Key Definitions and Keywords — Statistical Charts and Diagrams

Definitions to memorise and the exact keywords mark schemes credit for statistical charts and diagrams answers — sharpened from recent examiner reports for the 2026 0580 sitting.

Histogram
Examiner keyword
A bar-style chart for continuous data. With unequal class widths, the y-axis is frequency density and the AREA equals frequency.
Frequency density
Examiner keyword
Frequency divided by class width. Standardises bars so that AREA represents frequency.
Pie chart
Examiner keyword
A circular chart split into sectors proportional to frequency.
Box-and-whisker plot
Examiner keyword
A summary diagram showing min, $Q_{1}$ , median, $Q_{3}$ , max.

Common Mistakes and Misconceptions — Statistical Charts and Diagrams

The traps other students keep falling into on statistical charts and diagrams questions — taken from recent Cambridge IGCSE 0580 examiner reports and mark schemes — and how to avoid them.

✕Using frequency on the y-axis of a histogram with unequal classes
0580/42 — every series
Why it happens
Forgetting to convert to frequency density.
How to avoid it
Unequal classes → ALWAYS use frequency DENSITY. Bar AREA = frequency.
✕Pie sectors not summing to $360\degree$
Why it happens
Rounding errors.
How to avoid it
Check the four (or however many) sectors sum to exactly $360\degree$ . Adjust the largest by the rounding error if needed.
✕Gaps between histogram bars
Why it happens
Drawing it like a bar chart.
How to avoid it
Histograms have NO gaps — continuous data, bars touch.
✕Reading the box plot's middle line as the mean
Why it happens
Confusing mean and median.
How to avoid it
Box plot middle line = MEDIAN, not mean.

Practice questions

Exam-style questions with step-by-step worked solutions. Try one before checking the method.

Past paper style quiz

Get a report showing which sub-topics you've nailed and which ones still need work.

Video lesson

Short walkthrough of the concepts students most often get stuck on.
